ABB ROBOTICS · IRC5 MAIN DRIVE UNIT

3HAC14546-4

The ABB 3HAC14546-4 is a DSQC 617 main servo drive unit identified as the 3G3T variant for an IRC5 M2004 drive-module configuration.

MODEL3HAC14546-4
BRANDABB
SYSTEM / APPLICATIONIRC5 M2004 drive module
VERIFICATIONDSQC 617_3G3T
MANUFACTURERABB
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Informeer nu
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ↗ABB ROBOTICS · IRC5 MAIN DRIVE UNIT
DSQC 617 MAIN SERVO DRIVE UNIT

3HAC14546-4

DSQC 617_3G3T · IRC5 M2004

main servo drive unit · IRC5 M2004 drive module.

PRODUCT ROLE

3HAC14546-4 is the DSQC 617_3G3T main servo drive variant used within a compatible ABB IRC5 M2004 drive module.

CONFIGURATION NOTE

Confirm the DSQC 617_3G3T designation, installed drive position, controller generation, DC-bus connections, motor connections and system parameters before replacement.

👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the 3HAC14546-4 reference is identified

DSQC 617_3G3T
Model
3HAC14546-4
Part number
ABB MANUFACTURER-REFERENCE DATA

Technical Specifications

ABB IRC5 PRODUCT MANUAL
General Information−
BrandABB
Part number3HAC14546-4
Official descriptionmain servo drive unit
Robot applicationIRC5 M2004 drive module
ColorDSQC 617_3G3T
Configuration noteDSQC 617_3G3T · IRC5 M2004
Official Spare-Parts Identification+
ManufacturerABB
Part number3HAC14546-4
Manual descriptionmain servo drive unit
Manual locationIRC5 M2004 drive module, item 59
Compatibility Control+
System matchMatch the IRC5 M2004 drive-module build and the installed 3G3T designation.
Installed contextRecord all motor, DC-bus, feedback and control connections before disconnection.
Variant matchDSQC 617_3G3T
Replacement controlDo not substitute the -1 or -2 variants because their drive designations and axis assignments differ.
Installation and Replacement Check+
Service conditionDischarge and isolate the drive-module DC bus before removing the servo drive.
Connection recordRecord all motor, DC-bus, feedback and control connections before disconnection.
Identification evidenceProvide the controller label, drive-module layout and DSQC designation.
Final identity checkConfirm the DSQC 617_3G3T designation, installed drive position, controller generation, DC-bus connections, motor connections and system parameters before replacement.
Manual and Final Confirmation+
ABB manualABB IRC5 product manual
Document number3HAC021313-001
Listed applicationIRC5 M2004 drive module · main servo drive unit
Replacement limitationDo not substitute the -1 or -2 variants because their drive designations and axis assignments differ.

Source: ABB IRC5 product manual, 3HAC021313-001. Verify 3HAC14546-4 against the installed IRC5 M2004 drive module and the complete manufacturer article number.
