ABB CI501-PNIO AC500 PROFINET I/O Module
ABB CI501-PNIO AC500 PROFINET I/O Module
ABB CI501-PNIO AC500 PROFINET I/O Module

ABB CI501-PNIO AC500 PROFINET I/O Module

ABB AC500 / S500 · PROFINET IO

CI501-PNIO

The ABB CI501-PNIO is an AC500/S500 PROFINET I/O bus module with a two-port 100BASE-TX interface, integrated switch and onboard I/O. It connects S500 I/O expansion to a PROFINET IO controller.

NETWORKPROFINET IO
ETHERNET2 × RJ45 · 10/100 Mbps
EXPANSIONUp to 10 S500 Modules
SUPPLY24 V DC
MANUFACTURERABB
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Informeer nu
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ↗PROFINET IO DEVICE
AC500 / S500 COMMUNICATION INTERFACE

CI501-PNIO

1SAP220600R0001

PROFINET I/O bus module · 2-port 100BASE-TX interface · integrated switch · onboard digital and analog I/O.

PRODUCT ROLE

CI501-PNIO links ABB S500 I/O expansion to a PROFINET IO controller and provides two switched RJ45 network ports.

CONFIGURATION NOTE

Confirm order number 1SAP220600R0001, PROFINET project data, device-name switch settings, 24 V DC wiring and the connected S500 module arrangement before replacement.

ORDER NUMBER BREAKDOWN

How the CI501-PNIO order number is structured

CI501
Module familyCommunication interface
PNIO
Network variantPROFINET IO
1SAP220600R0001
ABB order numberComplete article reference
VERIFIED MANUFACTURER-REFERENCE DATA

Technical Specifications

ABB CI501-PNIO ↗
General Information−
BrandABB
ModelCI501-PNIO
Order number1SAP220600R0001
Product typePROFINET I/O bus module
Product familyAC500 / S500
Supported expansionMaximum 10 S500 I/O modules
PROFINET and Ethernet Data+
Ethernet interface100BASE-TX with integrated switch
Connections2 × RJ45 sockets
Transfer rate10/100 Mbit/s, full duplex
Transfer methodEthernet II, IEEE 802.3
Minimum bus cycle1 ms
Conformance classCC B
Supported servicesRTC class 1, RTA, DCP, CL-RPC, LLDP and MRP client
Integrated I/O Data+
Digital inputs8 channels
Digital outputs8 channels
Analog inputs4 channels
Analog outputs2 channels
Input data length19 bytes
Output data length23 bytes
Status indication32 LEDs
Power and Installation+
Process supply24 V DC for inputs and outputs
Maximum terminal load10 A
Rated fuse10 A, fast
Normal current consumption0.2 A at UP
Maximum power dissipation6 W
MountingHorizontal or vertical with stated derating
CoolingNatural convection; ventilation must not be obstructed
Protection and Diagnostics+
Bus protectionShort circuit, reverse supply, overvoltage and reverse polarity
Galvanic isolationBus interface isolated from the rest of the module
Supported alarmsProcess, diagnostic, return, plug and pull alarms
Device namingTwo rotary switches for explicit device name

Source: ABB CI501-PNIO Technical Data and ABB product page for order number 1SAP220600R0001. Values apply under ABB’s stated operating conditions.

SYSTEM APPLICATIONS

Where CI501-PNIO fits in the control architecture

PROFINET IO Device

Exchanges cyclic and acyclic data with the PROFINET IO controller.

S500 I/O Expansion

Supports a connected station of up to 10 S500 I/O modules.

SYSTEM INTERFACECI501-PNIOAC500 / S500
Switched Ethernet Link

Two RJ45 ports provide an integrated 100BASE-TX switch.

Integrated I/O

Provides local digital and analog I/O within the same station.

FAQ

Questions Buyers Ask Most

What is CI501-PNIO used for?+
CI501-PNIO is an ABB AC500/S500 PROFINET I/O bus module that connects an S500 I/O station to a PROFINET IO controller. The module combines two switched Ethernet ports, integrated I/O and expansion for up to 10 S500 I/O modules.
Does CI501-PNIO support ordinary Ethernet only?+
No. CI501-PNIO uses a 100BASE-TX Ethernet physical interface, but its device function is PROFINET IO. It supports the ABB-documented PROFINET services and conformance class CC B, so the controller project and device configuration must be compatible.
How many S500 I/O modules can CI501-PNIO support?+
CI501-PNIO supports a maximum of 10 connected S500 I/O modules. The final station must also satisfy ABB’s power, data-length, mounting and temperature requirements.
Are the two RJ45 ports on CI501-PNIO two separate devices?+
No. The two RJ45 sockets on CI501-PNIO belong to the integrated Ethernet switch of one PROFINET IO device. They support network topology and forwarding rather than two independent device identities.
What must be checked before replacing CI501-PNIO?+
Before replacing CI501-PNIO, confirm order number 1SAP220600R0001, the standard or XC hardware version, 24 V DC supply wiring, PROFINET device name, GSD/project configuration and the connected S500 I/O module arrangement.
Can CI501-PNIO be installed vertically?+
Yes. ABB permits vertical installation of CI501-PNIO with specified derating. At +40 °C, the digital output loading is reduced to 50 percent per group, and natural-convection clearance must remain unobstructed.
Which onboard I/O is included with CI501-PNIO?+
CI501-PNIO includes 8 digital inputs, 8 digital outputs, 4 analog inputs and 2 analog outputs. Channel configuration and connected loads must follow the ABB technical instructions for the required AC500/S500 application.
CONTACT PRODUCT SPECIALIST

Confirm your CI501-PNIO configuration with Frida

Share the complete order number, PROFINET project details and connected S500 I/O arrangement for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
OFFICIAL DATASHEET

ABB CI501-PNIO Product Information

Official ABB product and technical data for CI501-PNIO, complete order number 1SAP220600R0001.

CI501-PNIO Technical Data

ABB documents CI501-PNIO as a PROFINET I/O bus module for AC500/S500 with an integrated switch, two RJ45 ports, 10/100 Mbit/s full-duplex communication, onboard digital and analog I/O and expansion for up to 10 S500 I/O modules.

OFFICIAL DATASHEET ↗

Contact to Get Support

Send the complete model, quantity, PROFINET configuration and your technical or purchasing question.

Source: ABB official CI501-PNIO product page and ABB Automation Builder help for order number 1SAP220600R0001.

AC500 / S500 SYSTEM RELATIONSHIP

How CI501-PNIO fits into the ABB AC500/S500 system

ABB ↗ is the brand, AC500/S500 is the automation platform, CI501-PNIO is the complete module model, PROFINET I/O bus module is the product type, and 1SAP220600R0001 is the order configuration used with compatible S500 I/O modules.

BRAND / PLATFORMABB AC500 / S500
→
COMPLETE MODELCI501-PNIO
→
CONFIGURATION / SYSTEMPROFINET IO · 1SAP220600R0001
Controller Connection

PROFINET IO controller communication.

Network Topology

Two switched RJ45 Ethernet ports.

Local I/O

Integrated digital and analog channels.

Station Expansion

Up to 10 S500 I/O modules.

👩‍💼
