The 330380-90-00 High Temperature Proximity Sensor is designed to withstand the extreme temperatures found inside gas turbines, steam turbines and other types of rotating machinery.
Merk :
Bently NevadaOnderdeel nummer :
330380-90-00Gewicht :
0.2 kgDimensie :
8.8x3.5x7cmLand van herkomst :
USAHS-code :
8537101190Beschrijving :
High Temperature Proximitor Sensor
Contact Us
Email:sales5@mooreplc.com
Phone/Whatsapp/Wechat:+86 15359408275
330380-90-00
|
Description |
The 330380-90-00 is a 3300 XL 16mm High Temperature Proximitor Sensor. It is the signal conditioning component of the 3300 High Temperature Proximity System (HTPS). This sensor is designed to be used with a 3300 XL HTPS probe and matched extension cable to measure vibration, thrust position, and differential expansion inside the hot sections of gas and steam turbines and other rotating machinery where conventional proximity probes would be damaged by extreme heat. |
330380-90-00
|
Specifications |
Brand: Bently Nevada
Operating Temperature (Proximitor):-52°C to +100°C (-60°F to +212°F) |
|
|
|
|
|
|
|
|
330380-90-00
|
Application |
Gas Turbine Monitoring: Measuring vibration and position in areas where probe cables are routed through hot bearing support struts or the exhaust path. |
|
|
|
|
|
|
|
|
330380-90-00
FAQ
What is the primary function of the 330380-90-00 Proximitor Sensor?
The 330380-90-00 is a signal conditioner for the 3300 High Temperature Proximity System (HTPS). It accepts input from a matched high-temperature probe and extension cable, providing an output voltage proportional to the distance between the probe tip and a conductive surface. This allows for precise measurement of vibration and position in extreme heat.
Is the 330380-90-00 compatible with other Bently Nevada systems?
Yes, the 3.94 V/mm (100 mV/mil) signal output is compatible with virtually all new and existing Bently Nevada monitors and diagnostic equipment, including 3300 and 3500 series monitoring systems .
What are the other mounting options available for the 330380 model?
The 330380 model is available in different configurations based on the "-AA" option code:
330380-90-00: 9 meter system, panel mount.
330380-91-00: 9 meter system, DIN mount.
330380-92-00: 9 meter system, no mounting hardware.
Does this sensor require special calibration for use?
No. The 330380-90-00 and its associated system components (probe and extension cable) are factory-calibrated as a matched set. It is ready for installation and immediate operation upon delivery.
Can this sensor be used in environments with high humidity?
Yes. The Proximitor Sensor can tolerate 100% condensing humidity and is submersible provided the connectors are properly protected.
