6ES7288-7DP01-0AA0 Slave Module

The 6ES7288-7DP01-0AA0 is an EM DP01 PROFIBUS DP slave module designed for use with the Siemens SIMATIC S7-1200 series. This module enables S7-1200 CPUs to communicate as slaves on a PROFIBUS DP network, allowing integration into larger distributed automation systems where a PROFIBUS DP master (such as an S7-300, S7-400, or S7-1500 CPU) controls the data exchange.

The module is a compact expansion module that connects to the left side of the S7-1200 CPU via the CPU's expansion interface. It supports PROFIBUS DP-V0 slave functionality and provides a RS-485 interface for network connection.

6ES7288-7DP01-0AA0 DETAILS

Product Type Designation: EM DP01, PROFIBUS DP slave module
Part Number: 6ES7288-7DP01-0AA0
Supply Voltage: 24 V DC
Permissible Range: 20.4 V to 28.8 V DC
Current Consumption (typ.): 15 mA
Current Consumption (max.): 30 mA
Power Loss (typ.): 2.5 W
RS 485 Interfaces: 1
PROFIBUS Support: Yes (DP slave)
PROFINET IO Support: No

6ES7288-7DP01-0AA0

Frequently Asked Questions (FAQ)

Q: What is the 6ES7288-7DP01-0AA0?
A: It is an EM DP01 PROFIBUS DP slave module for SIMATIC S7-1200 PLCs. It allows an S7-1200 CPU to communicate as a slave on a PROFIBUS DP network.

Q: What is the function of this module?
A: The module enables an S7-1200 CPU to exchange data with a PROFIBUS DP master (such as an S7-300, S7-400, or S7-1500 CPU) over a PROFIBUS network. This allows the S7-1200 to be integrated into larger automation systems.

Q: How is this module installed?
A: The EM DP01 module connects to the left side of the S7-1200 CPU via the CPU's expansion interface. It is mounted on a standard DIN rail and requires no additional external power supply (power is provided through the CPU).

Q: Does this module support PROFINET?
A: No. This module only supports PROFIBUS DP. For PROFINET functionality, the S7-1200 CPU itself provides integrated PROFINET ports.

Q: What is the PROFIBUS address setting?
A: The PROFIBUS address is set using the DIP switches located on the module. The address can be set between 1 and 125.

Q: What PROFIBUS communication rates are supported?
A: The module supports PROFIBUS DP communication rates from 9.6 kbit/s to 12 Mbit/s. The baud rate is automatically detected by the module.
